DC5V Infrared Beam Sensor Detector Alarm Photocell Photoelectric Switch Detect D
SKU: <none>
$6.99Price
SPECIFICATIONS
Brand Name: BADODOSECURITY
Origin: Mainland China
Smart home platform: none
Certification: none
Model Number: RAD100CM
Choice: yes
semi_Choice: yes
Specification：
Detect Distance : 1m
Work Voltage : DC5V
Work Current : 200mA
Output Current : 16mA ( Can directly connect to relay )
Output : NPN (NO, normal open )
Transmitter Angle : Line ( Infrared )
Receiver Angle : ＜ 10°
Response Time : 2ms
Work Temperature : -25 ~ 60 °C
Work Environment : Indoor ( Not waterproof )
The voltage between is 5V, and when there have an obstacle, the voltage is 0V
